FRAME STAR Series

Frame Star Series All-in-two Solar Street Light is a Half Split Solar Street LED Light. Continuous night lighting and durable die-cast aluminum materials will give you a good experience. As an outdoor lighting fixture, the Solar Light is powered by solar energy and designed to offer outstanding quality by utilizing A-class LED beads, an integrated optical LED lens, a high-efficiency mono solar panel, powerful lithium battery.

As the top supplier and manufacturer of All-in-two Solar Street lights, the features of our products are as follows:

(1) Positive A-level cells, each cell has a complete IV curve, and the conversion rate is as high as 19.5%.

(2) Lithium iron phosphate battery, the depth of discharge reaches 95%, and the service life is less than 0.5C at the discharge rate Up to 15 years, high safety factor.

(3) High lumen value LED patch, high lighting brightness and long lasting. Imported polycarbonate (PC) outdoor optical lens, with strong light transmission, high and low-temperature resistance, anti-aging, no deformation, and discoloration.

(4) High-quality cold-rolled sheet die-casting, anti-corrosion, long life, integrated design, beautiful and practical.

Power 20W 30W 50W 80W
Panel Watts(w) 5V/50W poly? 5V/65W poly 5V/120W poly 5V/135W mono
Lamp Common LED 20W Common LED 30W Common LED 50W Common LED 80W
Lumens 1800lm 3200lm 5400lm 7700lm
Battery 3.2V/35(±5) 3.2V/60Ah 3.2V/80Ah 3.2V/140Ah
Battery type LiFePO4 battery
Lighting time Whole night lighting, with remoted control
Install height 5-6M 8-10M

Solar Get Frame Star Series All-in-two Solar Street Light is widely used in streets and roads, residential areas, scenic spots, parks, squares, private gardens and other public places.

Frame Star Series

All-in-two solar street light also has an external battery that store and discharge electricity.

Here emphasize the issue of installation, the light should not be installed too low,  Don’t bury too shallow in order not to be stolen.

All-in-two solar street light has independent components, which is more flexible. The feature is easily designed according to the requirements of illumination.  It is very practical for areas with long-term rainy weather.

Get a Quote

Frame Star Series All-in-two Solar Street Light is a Half Split Solar Street LED Light. Continuous night lighting and durable die-cast aluminum materials will give you a good experience. As an outdoor lighting fixture, the Solar Light is powered by solar energy and designed to offer outstanding quality by utilizing A-class LED beads, an integrated optical LED lens, high-efficiency mono solar panel, powerful lithium battery.
